RANGER-LR LITE
*In stock and ready to ship
FLY IT, DRIVE IT, MOUNT IT ANYWHERE. THE MOST ADAPTABLE MAPPING SYSTEM
The RANGER-LR LITE is the new lighter Long Range system configuration of our RANGER Series. Designed for the most demanding mapping applications, the RANGER-LR LITE is the ultimate combination of high density, long range LiDAR with a powerful 1,550 nm laser that penetrates dense vegetation at high speeds and altitudes in large scan regions.
This system is available in UAV, vehicle, VTOL and backpack configurations, depending on your needs.
* In stock and ready to ship
15-30mm
RMSE @ 120 Range
1500k
Points per Second
400m
Rec. Max AGL
1000m
@ 20% Reflectivity
4.14kg
Weight
Featuring the new Phoenix LiDAR AIR NavBox
The NEW RANGER LITE includes Phoenix LiDAR’s new AIR NavBox. The newest generation, ultra-lightweight rover will help meet the rigorous demands of various industries and applications by greatly increasing flexibility in key areas:
- Reducing weight to allow longer flight-times on lighter UAVs.
- Much improved data throughput to accommodate multiple sensors producing more data as pixelcount and pulse repetition frequencies increase.
The new Phoenix LiDAR AIR NavBox offers the most industry-altering capabilities in a tiny box not much bigger than a standard-size computer mouse.
Dimensions:
60 x 125 x 50 mmWeight
450gControl via button, 4g, wifi or ethernet
Custom LiDAR Solutions
Phoenix LiDAR Systems
Build the system you need to meet the growing demands of your clients in varying industries, from mining to agriculture and construction to forestry.
-
Ideal for configuring heavier mapping payloads on the DJI M600
-
Survey-Grade (cm-level) accuracy with 250m+ laser range and outstanding intensity calibration on high altitude and high speed missions
-
Penetrates vegetation to produce accurate results
-
Free Phoenix Software Suite w/unlimited license; plus NovAtel & Terrasolid options also available (fee may apply)
-
High accuracy due to precision Fiber Optic Gyro IMU
-
Live/Remote Data Feed: View and analyze data in real time or transmit live data to remote viewers via 4G connection
The "Universal Soldier" of LiDAR mapping systems.
Optional Upgrades
-
Aerial systems
-
IMU and dual-GPS upgrade options for increased accuracy
-
Integrated UHF radio modem
-
Optional ground vehicle & UAV mounts/accessories
-
Service plans
Primary Applications
-
Vegetation Penetration
-
Utility Infrastructure
-
Open Pit Mining
-
Forestry
-
Construction Site Monitoring
-
Cultural Preservation
-
Glacier & Snowfield Mapping
-
Land Erosion
Navigation System
-
Integrated AIR NavBox
-
Constellation Support: GPS, GLONASS, BEIDOU, GALILEO
-
Support alignment: Kinematic, Dual-Antenna
-
Operation Modes: Real-time, Post-processing optional
-
Accuracy Position: 1cm + 1ppm RMS horizontal
-
PP Attitude Heading RMS Error: 0.007° / 0.009°
Platform Specs
-
Overall Dimensions, Sensor: 32.9 x 16.3 x 17.9cm
-
Operating Voltage: 12-28 V DC
-
Power Consumption: ~90 W
-
Weight: 3.85kg / 8.5lbs (5kg w/ 100MP Camera)
-
Operating Temperature: – 10˚ – 40˚ C
Flexible Mounting Options
The RANGER-LR-LITE is designed with flexible mounting options in mind. Easily mountable to unmanned platforms (UAVs) and to helicopters, gyrocopters, and other small manned aircrafts.
LiDAR Sensor Specs
1550nm
Laser Properties: Class 1 (eye safe)
25-35mm
Absolute Accuracy: RMSE @ 150m Range
15mm
Range Accuracy: One Sigma @ 150m
5m
Range Min.
750k points
Scan Rate
7x
Returns/Echoes
360°h degrees
Field of View
10-100 Hz
Mirror Speed
0.001°
Angle Measurement Resolution
∆ϑ: 0.06° ≤ ∆ϑ ≤ 1.5°
Angular Resolution (Horizontal/Azimuth)
50/250/100050mmmm
Laser Beam Footprint @ 100/500/1000m
∆ϑ 0.05° ≤ ∆ϑ ≤ 0.5°
Angular Step Width (between consecutive laser shots)
Phoenix Software Suite
Phoenix LiDAR Systems provides a proprietary complete software suite for streamlined acquisition, geo-referencing, data fusion, export and post-processing in the cloud.
Point Density Speed & Altitude
