TERRAHAWK CW-20



3hrs.

Flight Time

3.2m

Wingspan

25m/s

Cruise Speed

20k

Comm. Range

25kg

Max Take-off Weight

Custom VTOL LiDAR Solutions

Phoenix LiDAR systems


Build the TerraHawk system you need to meet the growing demands of your clients in varying industries, A strong choice for mapping utility corridors and tackling difficult surveying conditions at higher speeds and altitudes, the Phoenix TerraHawk CW-20 boasts 3-hour autonomous flight times, an auto-return system, and a backup auto-landing system that initiates safe, multi-rotor landings if an abnormality is ever detected.


  • Easy Assembly: 10-min assembly saves time in the field
  • Reduced Operational Footprint: No runway or launch/recovery equipment required, backup auto-landing system protects your LiDAR equipment
  • Large Scan Area: Map up to 11 sq. km. in one flight
  • Industry Leading Flight Time: Fly to 3 hours
  • Free basic online training included; PLUS complete Acquisition/Post-Processing/Pilot/Certification training also available (fees may apply)
  • Free Phoenix Software Suite w/unlimited license; plus NovAtel & Terrasolid options also available (fee may apply)
  • Modular Upgrade Options: Photogrammetry Options (RTK): RGB, NIR, DSLR
  • Autonomous Flight: Use waypoints for auto flight and return

Navigation System


  • Constellation Support: GPS, GLONASS
  • Support alignment: Static, Kinematic, Dual-Antenna
  • Operation Modes: Real-time, Post-processing optional
  • Accuracy Position: 1cm + 1ppm RMS horizontal
  • PP Attitude Heading RMS Error: 0.019 / 0.074°

Primary Applications


  • Vegetation Penetration & Forestry
  • Utility Infrastructure & Construction Site Monitoring
  • Open Pit Mining
  • Agriculture & Land Erosion
  • Cultural Preservation
  • Glacier & Snowfield Mapping

TerraHawk CW-20 + SCOUT Ultra

The strength & endurance of a VTOL combined with the most robust configuration of the Scout Series.

10min.

Assembly/Deployment Time

18kg / 22kg / 24kg

Weight (Aircraft/+Fuel/+LiDAR & Fuel)




Point Density Speed & Altitude

Flight Altitude (AGL)

Swath Width

80m ~160m
100m ~200m

Phoenix Software Suite

Included with all Phoenix LiDAR Systems packages


Phoenix LiDAR Systems provides a proprietary complete software suite for streamlined acquisition, geo-referencing, data fusion & export.
